Flame Retardant Fabric Linen Coated Blackout Fabric in Gray for Curtains, NF-P92-503-M1 compliant

SKU: BG-FMTC-04

Fire Retardant Blackout Anti-UV Soundproof
NFPA701, NF-P92-503-M1, BS5815
300cm
350gsm
100% Polyester
Flame Retardant
Usually we provide A4 size samples, samples are free, you only need to pay the shipping cost, if you need more sample quantity, please contact us.

Test Report for Flame Retardant Coated Fabric According to DIN4102-B1 Standard

  • Report Number: AJFS2209007335FF
  • Sample Description: Flame retardant coated fabric, color gray, composition polyester.
  • Test Requirements: According to DIN 4102-1:1998-05 standard, the fire behavior of building materials and elements is classified, testing for Class B1 materials.
  • Test Results: The sample meets the requirements of Class B1 materials as per DIN 4102-1:1998-05 standard.
  • Test Details:
  • Brandschacht Test:

Exposed Surface: White surface

Maximum Flame Height: 40 cm (lengthwise), 40 cm (widthwise)

Flame Persistence Time: 00:38 (lengthwise), 00:44 (widthwise)

Melting/Burning Through: Yes (both lengthwise and widthwise)

Back of Specimen Ignition: Yes (both lengthwise and widthwise)

Flaming/Glowing Droplets: Yes (both lengthwise and widthwise)

Ignition Time: 00:20 (lengthwise), 00:23 (widthwise)

Specimen Material Falling Off in Separate Droplets: Yes (both lengthwise and widthwise)

Residual Length: Average 62.3 cm (lengthwise), Average 65.5 cm (widthwise)

Smoke Temperature: Maximum Average 154.7 °C (lengthwise), Maximum Average 151.8 °C (widthwise)

  • Ignitability Test:

Flame Application Time: 15 seconds

Flaming Reaching the Gauge Mark Within 20 Seconds: No (both lengthwise and widthwise)

Afterflame Time: Ranging from 2 to 4 seconds

Maximum Flame Height: Ranging from 5 to 9 cm

Molten Dripping: No (both lengthwise and widthwise)




Test Report for M1 Inherent Flame Retardant Blackout Fabric

  • Report Number: AJFS2405006006FF
  • Sample Description: Inherent flame retardant blackout fabric, color white, composition 100% polyester.
  • Test Requirements: According to NF P 92-507:2004 standard, the fire reaction of building interior fitting materials is classified.
  • Test Results: The sample is classified as M1 level.
  • Test Details:
  • Electrical Burner Test (NF P 92-503:1995):

Hole Formation During Testing: Yes

Application Time: 20 seconds

Maximum Afterflame Time: 0 seconds

Flaming Molten Droplets: No

Non-flaming Molten Droplets: No

Flaming Debris: No

Non-flaming Debris: No

White-hot Spots with Propagation Effects: No

Maximum Destruction Length: Average 40 mm

Destroyed Width: 0 mm

  • Flame Persistence Test (NF P 92-504:1995):

Ignition Time: 0 seconds

After-flame Time: Ranging from 0 to 30 seconds

Flaming Drops: No

Non-flaming Drops: No
