Inherent Flame Retardant Bedding Fabric Flame Resistant Woven Polyester Fabric
SKU: BG-DS-120
- NFPA701,DIN4102-B1,CANULC-S109-14,CA TITLE 19 section1237,BS5815-3,BS7175,BS5852 SOURCE 5
- 230cm
- 115gsm
- flame retardant
- 100% polyester
Usually we provide A4 size samples, samples are free, you only need to pay the shipping cost, if you need more sample quantity, please contact us.
Test Report Summary: BS7175 Ignitability Test for Bedcovers and Pillows
- Sample Description: Inherent Flame Retardant Duvets (75*24)
- Color: Gray
- Composition: Polyester
- Test Requested: BS 7175:1989 – Methods of Test for Ignitability of Bedcovers and Pillows by Smouldering and Flaming Ignition Sources, Section 2
- Conclusion: Non-ignition (NI) for all test specimens under Ignition Source 7 (Crib 7).
Test Details
- Sample Description: Duvet
- Sample Size: 650mm x 650mm
- Conditioning: Specimens and cribs were conditioned for 72 hours in ambient conditions, then for at least 16 hours at 20±5℃ and 65±5% humidity.
Test Results
Ignition Source Position (a: Upper Surface, b: Beneath Overhang 100mm):
| Test No. | Ignition Source | Progressive Smouldering (PS) | Flaming (F) | Duration of Ignition Source (min) | Duration of Flames (min) | Duration of Smoke (min) | Extent of Damage (Length, mm) |
|---|---|---|---|---|---|---|---|
| 1st (a) | Crib 7 | No | No | 5:09 | 9:26 | 10:02 | 331 |
| 2nd (a) | Crib 7 | No | No | 5:17 | 8:20 | 9:03 | 335 |
| 1st (b) | Crib 7 | No | No | 5:11 | 2:02 | 5:46 | 150 |
| 2nd (b) | Crib 7 | No | No | 5:09 | 1:39 | 5:50 | 150 |
Observations
- Progressive Smouldering: No
- Flaming: No
- Final Examination of Smouldering: None
- Test Result: Non-Ignition (NI) for all specimens
- Photo Appendix: SGS authenticated the photo on the original report.
